The TTL6-AS is a high power line source active bass module designed to provide high output level indoors and outdoors for medium to large venues. The TTL 6-AS is the ideal bass module for the TTL6-A, extending the frequency range of the suspended system and improving the bass output level.
The TTL6-AS module is equipped with 3 x 12″ low frequency woofers in a bass reflex configuration. The integration of three channels of digital amplification and advanced digital processing set a new standard for distortion, noise and thermal efficiency.
3 Class D amplifiers, 1650 Watt total power
Premium quality DSP with optimized phase response
3x 12” compression driver
139 dB max SPL
RCF TTL6-AS Active Line Array Bass Module for TTL6-A 3-Way System
25,358 د.إ
Description
RCF TTL6-AS Active Line Array Bass Module for TTL6-A 3-Way System
acoustic specifications
FREQUENCY RESPONSE:35 Hz ÷ 400 Hz
SPL MAX. AT 1 M:139 dB
power section
TOTAL POWER:3300 W Peak, 1650 W RMS
LOW FREQUENCIES:3300 W Peak, 1650 W RMS
REFRIGERATION: Convection/Forced
Physical specifications
Size
HEIGHT:
1100 mm / 43.31 inches
OVERALL WIDTH:
378 mm / 14.88 inches
