The RCF TTL 36-AS is the ideal flyable bass complement for the TTL55-A array system. The clam-shell design guarantees the maximum output per size while the 2 x 4.5” voice coil vented 18” woofer design offers the minimum of power compression. The TTL36-AS is perfect to create flown systems for theatrical and indoor requirements. For very large outdoor systems is the perfect complement to reinforce the TTL55-A bass performance in combination with the ultra-powerful TTS56-A subwoofers.
4000 Watt (2 x 2000 W digital switching amplifiers)
2 x 18″ high power neodymium woofer, 4.5″ v. c.
96 Khz, 32 bit DSP processing
RCF TTL 36-AS ACTIVE LINE ARRAY SUBWOOFER MODULE
45,100 د.إ
Description
RCF TTL 36-AS ACTIVE LINE ARRAY SUBWOOFER MODULE
Acoustical specifications
FREQUENCY RESPONSE:35 Hz ÷ 120 Hz
MAX SPL @ 1M: 142 dB
Transducers
WOOFER:2 x 18” neo, 4.5” v.c
Input/Output section
INPUT CONNECTORS:
XLR, RDNet Ethercon
OUTPUT CONNECTORS:
XLR, RDNet Ethercon
INPUT SENSITIVITY:
-2 dBu/+10 dBu
Processor section
HI-PASS FREQUENCIES:
100 Hz
LOW-PASS FREQUENCIES:
80 Hz
Power section
TOTAL POWER:
8000 W Peak, 4000 W RMS
LOW FREQUENCIES:
8000 W Peak, 4000 W RMS
COOLING:
Convection/Forced
Physical specifications
Size
HEIGHT:
536 mm / 21.1 inches
WIDTH:
1022 mm / 40.24 inches
DEPTH:
970 mm / 38.19 inches
WEIGHT:
120 kg / 264.55 lbs
Additional information
| Condition | Unboxed |
|---|
